ACPI version: | 5.0 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Chipset (motherboard): | AMD |
Compatible processor series: | AMD Ryzen 3 AMD Ryzen 5 AMD Ryzen 7, 3rd Generation AMD Ryzen 9, AMD Ryzen 9 5th Gen |
Desktop Management Interface (DMI) version: | 2.7 |
ECC: | Yes |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 64 GB |
Maximum resolution: | 4096x2160 pixels |
Memory clock-frequency: | 2133 MHz 2400 MHz 2667 MHz 2933 MHz 3200 MHz 3400 MHz 3466 MHz 3600 MHz 3733 MHz 3866 MHz 4000 MHz 4133 MHz 4266 MHz 4400 MHz 4600 MHz 4800 MHz 5100 MHz |
Memory clock-frequency (max): | 5100 MHz |
Memory module type: | DIMM |
Memory number of slots: | 2 |
Memory type: | DDR4 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Non-ECC: | Yes |
Number of M.2 (M) slots: | 1 |
Number of SATA III connectors: | 4 |
PCIe x1 slots: | 1 |
PCIe x16 slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | AMD |
Processor socket: | Socket AM4 |
Processor socket(s) supported: | Socket AM4 |
RAID support: | Yes |
Storage interfaces supported: | M.2, Serial-ATAIII |
Trusted Platform Module (TPM) connector: | Yes |
USB port(s) quantity type: | USB Type-A |
USB2.0 port(s) quantity: | 2 |
USB3.2 Gen 1 (3.1 Gen 1) Type-A port(s) quantity: | 4 |
USB3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
VGA (D-Sub) port(s) quantity: | 1 |
Wireless LAN: | No |
