1st M.2 highest PCIe generation: | 4.0 |
1st M.2 largest key size: | 22110 |
2nd M.2 highest PCIe generation: | 3.0 |
2nd M.2 largest key size: | 22110 |
ACPI version: | 5.0 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Chipset (motherboard): | AMD |
Compatible processor series: | AMD Ryzen 3000 Series AMD Ryzen 4000 Series AMD Ryzen 5000 Series |
Cooling type: | Passive |
DVI-D port(s) quantity: | 0 |
Desktop Management Interface (DMI) version: | 2.7 |
ECC сompatibility: | ECC & Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 128 GB |
Maximum resolution: | 4096x2160 pixels |
Memory clock-frequency: | 3200 MHz 2933 MHz 2667 MHz 2400 MHz 2133 MHz |
Memory clock-frequency (max): | 3200 MHz |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR4 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 2 |
Number of SATA III connectors: | 4 |
PCIe x1 (Gen 3.x) slots: | 4 |
PCIe x16 (Gen 4.x) slots: | 1 |
Processor manufacturer: | AMD |
Processor socket: | Socket AM4 |
Processor socket(s) supported: | Socket AM4 |
RAID support: | Yes |
Storage interfaces supported: | M.2, PCIe 4.0, Serial-ATAIII |
Trusted Platform Module (TPM) connector: | Yes |
USB2.0 port(s) quantity: | 2 |
