1st M.2 largest key size: | 2280 |
ATX Power connector (24-pin): | Yes |
Audio output channels: | 7.1 channels |
Bluetooth port: | Yes |
Chipset (motherboard): | AMD |
Compatible processor series: | AMD Ryzen 3000 Series AMD Ryzen Threadripper 3000 Series AMD Ryzen Threadripper PRO 3000 WX-Series |
DVI-D port(s) quantity: | 1 |
Discrete graphics support: | Yes |
DisplayPorts quantity: | 1 |
ECC сompatibility: | ECC & Non-ECC |
Ethernet LAN: | Yes |
Ethernet LAN RJ-45 port(s) quantity: | 1 |
Ethernet interface type: | 10/ 100/ 1000 Mbps |
Form factor (Motherboard): | Micro-ATX |
Front panel audio connector: | Yes |
Front panel connector: | Yes |
HDCP support: | Yes |
HDMI port(s) quantity: | 1 |
Maximum memory size: | 128 GB |
Maximum number of SMP processors: | 1 |
Maximum resolution: | 5120x2880 pixels |
Memory clock-frequency: | 2133 MHz 2400 MHz 2667 MHz 2933 MHz 3200 MHz 3300 MHz 3333 MHz 3400 MHz 3466 MHz 3600 MHz 3733 MHz 3800 MHz 3866 MHz 4000 MHz 4400 MHz 4733 MHz
|
Memory clock-frequency (max): | 4733 MHz |
Memory module type: | DIMM |
Memory number of slots: | 4 |
Memory type: | DDR4 |
Multi-GPU (SLI/CrossfireX) support: | Not supported |
Number of HDDs supported: | 4 |
Number of M.2 (M) slots: | 1 |
Number of SATA II connectors: | 0 |
Number of SATA III connectors: | 4 |
Number of displays supported: | 3 |
PCIe x1 (Gen 3.x) slots: | 2 |
PCIe x16 (Gen 3.x) slots: | 1 |
PS/2 port(s) quantity: | 1 |
Processor manufacturer: | AMD |
Processor socket: | Socket AM4 |
Processor socket(s) supported: | Socket AM4 |
RAID support: | Yes |
SATA connectors quantity: | 4 |
Storage interfaces supported: | M.2, Serial-ATAIII |
